Current Solutions - Your OEM Power Source
800-933-7725

AC/DC Power Supplies :: Open Frame | Enclosed | U-Chassis

Adapter Tech

Series  DataSheet    Power  Input RangeOutputsDimensionsFeatures

Adapter-Open Frame-40~65W		PDF40100~240VSingle 9V, 12V, 15V, 18V, 19V, 20V, 24V, 48V123x 53x 30mmCustomer Design

Adapter-Open Frame-120W		PDF120100~240VSingle 24VCustomer Design

Adapter-OpenFrame		PDF144100~240V/50~60Hz, 2A max.Multiple 5V, 12V, 24V80x120x33mmCustomer Design

APTronic

Series  DataSheet    Power  Input RangeOutputsDimensionsFeatures

Telephone Exchange 3192		PDF020 – 60 VDC-5V, -12V, 5V, 12V109.3 x 92.42mmOpen Frame, Enclosed, U-Chassis

German Medical Product Law (MPG)		PDF0230V - Version: 196 – 264 VAC; 110V - Version: 95 – 135 VAC230V: 9V, 110V: 0-30V85 x 100 x 50mmChassis

Banking Systems		PDF090 – 264 VACThe power supply provides multiple switchable DC-outputs, which can customized according to the specific requirement.55mm–65mm x 240mm–400mm x 200–300mmOpen Frame, Enclosed

AUX-PSU		PDF093 - 260 VAC48VOpen Frame

Arch Electronics

Series  DataSheet    Power  Input RangeOutputsDimensionsFeatures

AES60O		PDF6085~265 VAC or 100~370 VDCSingle 5, 9, 12, 15, 24, 484.1 x 2.05 x 1.0 In
103.9 x 52.1 x 25.4 mm		Open Frame

AES60U		PDF6085~265 VAC or 100~370 VDCSingle 5, 9, 12, 15, 24, 484.13 x 2.28 x 1.5 In
105.0 x 58.0 x 38.1 mm		U Bracket

AES60E		PDF6085~265 VAC or 100~370 VDCSingle 5, 9, 12, 15, 24, 484.13 x 2.28 x 1.5 In
105.0 x 58.0 x 38.1 mm		Enclosed Frame

AQF120O		PDF12090~264 VAC or 100~370 VDCSingle 12, 24, 485.0 x 3.0 x 1.16 In
127.0 x 76.2 x 29.5 mm		Open Frame

AQF120U		PDF12090~264 VAC or 100~370 VDCSingle 12, 24, 485.0 x 3.24 x 1.5 In
127.0 x 82.2 x 38.1 mm		U Bracket

AQF120E		PDF12090~264 VAC or 100~370 VDCSingle 12, 24, 485.0 x 3.24 x 1.5 In
127.0 x 82.2 x 38.1 mm		Enclosed Frame

ALF150 Series		PDF15090~305VAC12V-54V6.44x 2.79x 1.5 inches

ALF240 Series		PDF19290~264VAC12V-48V8.35x 2.76x 1.5 inches

AQF240U		PDF24090~264 VAC or 120~370 VDCSingle 12, 12, 486.0 x 4.18 x 1.38 In
150.0 x 106.0 x 35.0 mm		AC-DC U Bracket

AQF240E		PDF24090~264 VAC or 120~370 VDCSingle 12, 12, 486.0 x 4.18 x 1.38 In
150.0 x 106.0 x 35.0 mm		AC-DC Enclosed Frame

AQF360U		PDF36090~264 VAC or 120~370 VDCSingle 12, 24, 486.8 x 3.2 x 1.5 In
172.7 x 81.3 x 38.0 mm		AC-DC U Bracket

AQF360E		PDF36090~264 VAC or 120~370 VDCSingle 12, 24, 486.8 x 3.2 x 2.1 In
172.7 x 81.3 x 53.3 mm		AC-DC Enclosed Frame

Cincon

Series  DataSheet    Power  Input RangeOutputsDimensionsFeatures

CFM05		PDF585-264VACSingle 3.3V, 5V, 9V, 12V, 15V, 18V, 24V2.165 x 1.378 x 0.827 inches
55 x 35 x 21mm		AC-DC Converter Open Frame

CFM10/15		PDF1085-264VACSingle 3.3V, 5V, 9V, 12V, 15V, 24VCFM10: 2.559 x 1.772 x 0.906 inches, 65 x 45 x 23mm
CFM15: 2.752 x 1.89 x 0.906, 69.90 x 48 x 23mm		AC-DC Converter Open Frame

CFM10		PDF10Universal3.3, 5, 12, 15, 241.77" W x 2.56" L x .91" H
65 x 45 x 23 mm		Open Frame, PCB Mountable

CFM15		PDF10Universal3.3, 5, 12, 15, 241.77" W x 2.56" L x .91" H
65 x 45 x 23 mm		Open Frame, PCB Mountable

CFM20		PDF2085-264VACSingle 3.3V, 5V, 9V, 12V, 15V, 24V3.501 x 2.000 x 0.906 inches
88.92 x 50.80 x 23.00mm		AC-DC Converter Open Frame

CFM40/60		PDF4090-264VACSingle 3.3V, 5V, 9V, 12V, 15V, 24V, 30V, 36V, 48V4.00 x 2.00 x 1.20 inches
101.60 x 50.80 x 30.48		AC-DC Converter Open Frame

CFM40D/T		PDF4090-264VACDual, Triple 4.00 x 2.00 x 1.063 inches
101.60 x 50.80 x 27.00mm		AC-DC Converter Open Frame

CFM60T		PDF6090-264VACTriple4.00 x 2.00 x 1.26 inches
101.60 x 50.80 x 32.00		AC-DC Converter Open Frame

CFM100		PDF10090-264VACSingle 5V, 9V, 12V, 15V, 18V, 24V, 48V5.00 x 3.00 x 1.339 inches
127.00 x 76.20 x 34.00mm		AC-DC Converter Open Frame

CFM101S		PDF10090-264VACSingle 12V, 15V, 24V, 48V2.0 x 4.0 x 1.1 inches
101.6 x 50.6 x 27.94mm		AC-DC Converter Open Frame

CFM200S		PDF20090-264VACSingle 3.3V, 5V, 9V, 12V, 15V, 18V, 24V, 28V, 30V, 36V, 48V5.91 x 3.94 x 1.5 inches
150 x 100 x 38.1mm		AC-DC Converter U Frame

CFM350S		PDF35090-264VACSingle 12V, 15V, 24V, 36V, 48V9.26 x 4.00 x 1.59 inches
235.2 x 101.6 x 40.40mm		AC-DC Converter U Frame

CFM351M		PDF35090~264VAC5V, 12V, 24V, 48V6.5x 4x 1.516 in

CFM750E		PDF75090-264VACSingle 24V, 36V, 48V11.02 x 4.00 x 1.65 inches
280.0 x 101.6 x 41.9mm		AC-DC Converter Enclosed

CFM1600H		PDF160090-264VACSingle 48V11.52 x 5.54 x 1.65 inches
292.6 x 140.7 x 42.0mm		AC-DC Converter Enclosed

Cotek

Series  DataSheet    Power  Input RangeOutputsDimensionsFeatures

MP05		PDF585~264VAC, 125~373VDC5V, 12V, 15V, 24V57.9x45x19.1 mm

MP10		PDF1085~264VAC, 125~373VDC5V, 12V, 15V, 24V65x45x22 mm

MP15		PDF1585~264VAC, 125~373VDC5V, 12V, 15V, 24V70x48x22 mm

MP20		PDF2085~264VAC, 125~373VDC5V, 12V, 15V, 24V88.9x50.8x19.3 mm

GE25		PDF2588~264VAC, 125~373VDC3.3V, 5V, 12V, 15V, 24V, 48V79x52x28mm

GE35		PDF3588~264VAC, 125~373VDC3.3V, 5V, 12V, 15V, 24V, 48V98x72x35mm

MP45 Dual Output		PDF4590~264VAC, 127~370VAC5V/12V, 5V/24V101.6x50.8x29 mm

MP45		PDF4590~264VAC, 127~370VAC5V, 12V, 15V, 24V101.6x50.8x29 mm

GE50		PDF5088~264VAC, 125~373VDC3.3V, 5V, 12V, 15V, 24V, 48V99x82x35mm

MP60 Dual Output		PDF6090~264VAC, 127~370VAC5V/12V, 5V/24V101.6x50.8x29 mm

MP60		PDF6090~264VAC, 127~370VAC5V, 12V, 15V, 24V101.6x50.8x29 mm

GE75		PDF7588~264VAC, 125~373VDC3.3V, 5V, 12V, 15V, 24V, 48V129x98x38mm

QE75		PDF7590~264VAC, 127~370VAC13.8V, 5V, 27.6V129.5x97.5x37.5

QP75		PDF7590~264VAC, 127~370VAC13.8V, 5V, 27.6V123x95x31 mm

AK75		PDF7590~264VAC, 127~370VDC5V, 7.5V, 12V, 13.5V 15V 24V 27V, 48V157x98x42mm

GE100		PDF10088~264VAC, 125~373VDC3.3V, 5V, 12V, 15V, 24V, 48V129x98x38mm

QE100		PDF10090~264VAC, 127~370VAC13.8V, 5V, 27.6V129.5x97.5x37.5

QP100		PDF10090~264VAC, 127~370VAC13.8V, 5V, 27.6V123x95x31 mm

AK100		PDF10090~264VAC, 127~370VDC5V, 7.5V, 12V, 13.5V 15V 24V 27V, 48V157x98x42mm

GE150		PDF15088~264VAC, 125~373VDC3.3V, 5V, 12V, 15V, 24V, 48V179x98x38mm

UP-150		PDF15090~264VAC, 127~370VAC12V, 15V, 20V, 24V, 30V, 36V, 48V198x68x33 mm

AK150		PDF15090~264VAC, 127~370VDC5V, 7.5V, 12V, 13.5V 15V 24V 27V, 48V197x98x42mm

UP-200		PDF20090~264VAC, 127~370VAC12V, 15V, 24V, 48V202x101.5x38 mm

AK200		PDF20090~264VAC, 127~370VDC5V, 7.5V, 12V, 13.5V 15V 24V 27V, 48V197x98x42mm

UP-350		PDF35090~264VAC, 127~370VAC12V, 15V, 24V, 48V231x101.5x38 mm

AK350		PDF35090~264VAC, 127~370VDC5V, 12V, 15V 24V, 48V119x105x41mm

AK450		PDF45090~264VAC, 127~370VDC5V, 12V, 15V 24V, 48V119x105x41mm

UP-500		PDF50090~264VAC, 127~370VAC12V, 15V, 24V, 48V254x127x38 mm

600U		PDF600180~260VAC, 260~370VDC5V, 9V, 12V, 15V, 18V, 24V, 30V, 36V, 48V, 60V284x105x63mm

AK650		PDF65090~264VAC, 127~370VDC5V, 12V, 15V 24V, 27V, 48V249x127x41mm

AK1000		PDF100090~264VAC, 127~370VDC12V, 15V 24V, 27V, 48V283x127x41mm

1K2U		PDF1200180~260VAC, 260~370VDC9V, 12V, 15V, 18V, 24V, 30V, 36V, 48V, 60V290x205x64mm

ME-1200		PDF120090~264VAC, 127~370VAC12V, 15V, 20V, 24V, 30V, 36V, 48V, 60V260.5x127x63.5 mm

1K5U		PDF1500180~260VAC, 260~370VDC9V, 12V, 15V, 18V, 24V, 30V, 36V, 48V, 60V290x205x64mm

AK1500		PDF150090~264VAC, 127~370VDC12V, 15V 24V, 27V, 48V280x127x63.5mm

AK3000		PDF300090~264VAC, 127~370VDC12V, 15V 24V, 27V, 48V305x127x127mm

Integrated Power Designs

Series  DataSheet    Power  Input RangeOutputsDimensionsFeatures

SRP-25		PDF2585~264 VACSingle, Dual or Triple2.25" x 4.0" x 0.96"Open Frame

SRP-30/35A		PDF3085~264 VAC; 47~63 HzSingle, Dual, Triple or Quadruple3"x 6"x 2"Enclosed

SRP-40A		PDF4085~264 VAC; 47~63 HzSinlge, Dual, Triple, or Quadruple2.5x 4.25x 1.2 inchesOpen Frame or Chassis/Cover

SRW-45		PDF4585~264 VAC; 47~63 HzSinlge, Dual, Triple, or Quadruple3"x 5"x 1.25"Open Frame or Chassis/Cover

SRW-65		PDF6585~264 VAC; 47~63 HzSinlge, Dual, Triple, or Quadruple4x 6x 1.1 inchesOpen Frame or Chassis/Cover

REL-70		PDF7085~264 VAC; 47~63 HzSingle, dual, Triple, or Quadruple2.5x 4.5x 1.2 inchesOpen Frame or Chassis/Cover

GRN-80S Series		PDF8085-264VAC3.3V2.5" x 4.25" x 1.0"

SRW-100		PDF10085~264 VAC; 47~63 HzSinlge, Dual, Triple, or Quadruple3.3x 5x 1.5 inchesOpen Frame or Chassis/Cover

NXT-100		PDF10085~264 VAC; 47~63 HzSingle2.5x 4.5x 1 inchesOpen Frame or Chassis/Cover

REL-110		PDF11085~264 VAC; 47~63 HzSingle, Dual, Triple, or Quadruple3x 5x 1.3 inchesOpen Frame or Chassis/Cover

SRW-115		PDF11585~264 VAC; 47~63 HzSinlge, Dual, Triple, or Quadruple4.25x 7x 1.25 inchesOpen Frame or Chassis/Cover

REL-150		PDF15085~264 VAC; 47~63 HzSingle, Dual, Triple, or Quadruple3.8x 6x 1.3 inchesOpen Frame or Chassis/Cover

CE-150		PDF15085~264 VAC; 47~63 HzSinlge, Dual, Triple, or Quadruple4x 7x 1.75 inchesU Bracket or Chassis/Cover

NXT-175		PDF17585~264 VAC; 47~63 HzSingle3x 5x 1.25 inchesOpen Frame or Chassis/Cover

REL-185		PDF18585~264 VAC; 47~63 HzSingle, Dual, Triple or Quadruple4.2x 7x 1.5 inchesOpen Frame or Chassis/Cover

CE-225		PDF22585~264 VAC; 47~63 HzSingle, Dual, Triple or Quadruple4.75x 8x 2 inchesU Bracket or Chassis/Cover

NXT-225		PDF22585~264 VAC; 47~63 HzSingle3.3x 5x 1.5 inchesOpen Frame or Chassis/Cover

CE-300		PDF30085~264 VAC; 47~63 HzSinlge, Dual, Triple, or Quadruple4.9x 8.5x 1.95 inchesEnclosed

NXT-325		PDF32585~264 VAC; 47~63 HzSingle3.9x 6x 1.5 mmOpen Frame

NXT-400		PDF40085~264 VAC; 47~63 HzSingle3.9x 8x 1.5 inchesOpen Frame or Chassis/Cover
