CHB50W
PDF Specs

Features

  • 25-50W Isolated Output
  • Half Brick Package
  • 4:1 Input Range
  • Regulated Outputs
  • Efficiency to 84%
  • 300KHz Switching Frequency
  • Five-Sided Shield Metal Case
  • Continuous Short Circuit Protection


Email
Quantity

General Specifications

ManufacturerCincon
Form FactorPCB Mount
Power25 Watts
Input9-36VDC, 18-75VDC
OutputsSingle 3.3V, 5V, 12V, 15V, 24V
Warranty2 years

Mechanical

Dimensions2.28 x 2.40 x 0.50 inches
57.9 x 61.0 x 12.7
Weight0.21 lbs
Operating Temperature-40oC to 100oC
Humidity95% RH (max.)
MTBF
Cooling Method
Agency ApprovalsUL

Output

Voltage Accuracy±1%
Line Regulation±0.2%
Load Regulation±0.2%
Minimum Load0
ProtectionsContinuous Short Circuit Protection

Models

Model #Output
CHB50W-24S333.3
CHB50W-24S055
CHB50W-24S1212
CHB50W-24S1515
CHB50W-24S2424
CHB50W-48S333.3
CHB50W-48S055
CHB50W-48S1212
CHB50W-48S1515
CHB50W-48S2424
